Network of Secure Sensors (VO NOSS)

· Windows10 or Window11 native application

· IP based. Runs over any IP Transport including public internet, WiFi (thru NAT and Firewalls), Starlink, Tactical Radio, etc

· View sensor status symbolically on map,

· View detailed sensor status

· Remotely Manage up to 750 sensors as a group for remote configuration batch changes to user defined grouping

· Sensor configuration and status via MS SQL Database at the VO NOSS location.

· Sentinel Software (also Windows 10/11 native) on each sensor manages configuration and reports status

o Reports per User Defined Signal of Interest (SOI) event to NOSS Consol and via email, SMS, etc

o Records IQ data up to 10s before and after SOI event.

o Remotely access data to upload for analysis or replay at Console or on Remote local node

A diagram of a computer system A map of the united states A screenshot of a computer

RF Sensors

Specification	VO UHF/SHF Sensor	VO Low Cost UHF/SHF Sensor	VO LF/HF/VHF Sensor:
Frequency Range	70 MHz to 6 GHz	1 MHz to 6 GHz	0.3 kHz to 65 MHz (upconvert) / 0.3 kHz to 3 GHz (passthrough)
Sampling Rate	Up to 61.44 MSPS	Up to 20 MSPS	Up to 20 MSPS
Resolution	12-bit	8-bit	8-bit
Channel Bandwidth	200 kHz to 20 MHz	Software-configurable	Software-configurable
Output Power	+7 dBm to +8 dBm	Software-controlled	Software-controlled
Frequency Range	70 MHz to 6 GHz	1 MHz to 6 GHz	0.3 kHz to 65 MHz
Sampling Rate	Up to 61.44 MSPS	Up to 20 MSPS	Up to 20 MSPS
Resolution	12-bit	8-bit	8-bit
Channel Bandwidth	200 kHz to 20 MHz	Software-configurable	Software-configurable

Other Options for Sensor Integrated with VO NOSS for remote access:

· Radiation detection: Beta, Gamma and X-Ray

· Detectable Energy Range: 0.1~3.0 MeV

· Own Background: 0,2 Pulses/s

· Working Voltage: 3.2-4.0VL

· CD Display: Dot matrix with back light

· Working power: 0.045W - 0.2W

· Main unit size: 5 x 2.8 x 1 inches

· Weight: 4 oz

· Automatic data recording.
